    Sliding Structure Medical 150T Fast Liquid Silicone Injection Molding Machine

    Ask Lasest Price
    Brand Name : TYM
    Model Number : TYM-L6068-2
    Certification : CE, ISO
    Price : Negotiation
    Supply Ability : 10 sets / month
    Delivery Time : 60 work days
    • Product Details
    • Company Profile

    Sliding Structure Medical 150T Fast Liquid Silicone Injection Molding Machine

    Sliding Structure Medical 150T Fast Liquid Silicone Injection Molding Machine


    There are five solutions to solve the problem of flow liner in liquid silicone injection molding machine


    1. Solution to mold problems of liquid silicone injection molding machine:

    A. Turn down the mold temperature

    B. Do vacuum treatment


    C. Enlarge the gate

    2. Solution to injection problem of liquid injection molding machine:

    ① Increase the injection pressure and increase the amount of product glue

    ② Increase the injection pressure and speed, and lower the temperature

    3. Too thin wall thickness of products, resulting in premature curing solution

    Lower the mold temperature, increase the injection pressure and speed of the product, and adjust the performance of silica gel (i.e., increase the fluidity of glue volume)

    4 material problem solution

    The fluidity of the product and the decrease of vulcanizing agent can adjust the physical properties of raw materials

    5, machine feeding system a, B glue and C color paste measurement accuracy ratio, through mixing and stable work problems.

    Adjust the accuracy and stability of color paste pump


    LSR injection molding machine of model TYM-L6068-2:




    The vertical 150T direct pressure LSR injection molding machine


    Injection Unit
    Shot Volume300g (can be adjusted)
    Injection Rate30 g/s
    Injection Pressure700kg/cm³
    Clamping Unit
    Clamping Force150 T
    Opening Stroke250-550 mm
    Tie-Bars Pace600*680 mm
    Ejection Force4.3 T
    Ejection Stroke150 mm
    Others
    Motor Power12.1 KW
    Pump Pressure21 Mpa
    Machine Weight5.5 T
    Machine Dimension2.7*1.7*3.4 M

    OUR SERVICES


    Pre-sale service
    According to the customer’s investment budget, plant planning and other forms of pre-sales services to ensure customer's planning is reasonable, standardized and cost-saving, will provide matched mold and select suitable machine according to customer’s requirement.


    On-purchase service
    Enable to be familiar with the operation and maintenance of the TYM's machine.
    1) Installation of LSR machine and new machine debugging service.
    2) Machine operator training.
    3) Training of technicians.


    After-sales service
    1) Free training for the operation and maintenance independently.
    2) Help to solve and reply technical problem and question timely, TYM will arrange professional engineer for the instruction and will provide the technical guidance for free.
    3) TYM will give priority to customer when the system on the LSR machine need to be upgraded.
